Dell M.2 PCIe Dual SSD Adapter Card 0NTRCY 023PX6
Inclusive of VAT · Warranty included
DELL
Product Specification
| Brand | DELL |
| SKU | ADP-DELL-M2-PCIe-2X |
| Product Type | M.2 PCIe Dual SSD Adapter Card |
| Part Numbers | 0NTRCY / 023PX6 |
| Card Type | PCIe Expansion Card |
| Drive Support | 2x M.2 NVMe SSD |
| Use Case | Server and Workstation Use |
| Feature | Supports NVMe Boot and Storage |
About This Product
Overview
The Dell M.2 PCIe Dual SSD Adapter Card is a practical storage expansion accessory for server and workstation environments. Designed to fit into a PCIe expansion slot, it provides support for two M.2 NVMe SSDs, making it a useful option when you need to add fast flash storage without changing the core system platform. With Dell part numbers 0NTRCY and 023PX6, this adapter card is a straightforward choice for IT teams looking to match compatible hardware with existing Dell systems. It is intended for server and workstation use and can be used for NVMe boot and storage applications, helping support flexible deployment needs in business computing environments.
Performance & Scalability
By using a PCIe-based adapter design, this card allows M.2 NVMe drives to connect through the system expansion architecture rather than relying on onboard storage only. That makes it well suited to builds where storage performance and expandability matter. Supporting two M.2 NVMe SSDs gives administrators more options for configuring boot drives, application storage, or high-speed data volumes depending on the system layout and workload requirements. In server and workstation settings, this kind of flexibility can be valuable when balancing capacity, speed, and available internal space. It is a useful component for environments that need to scale storage in a compact and efficient way while keeping the system organized around standard PCIe expansion.
Storage Flexibility
This adapter card is designed to help integrate M.2 NVMe SSDs into systems that support PCIe expansion. That makes it a versatile storage accessory for users who want to add or repurpose fast SSDs in a server or workstation build. Because it supports two drives, it can be used in a variety of storage layouts depending on the system configuration and operating requirements. The ability to support NVMe boot and storage adds further flexibility, especially in environments where fast access to system files or application data is important. For IT hardware buyers, this kind of adapter can simplify storage planning by making M.2 NVMe deployment possible in systems with the right PCIe slot availability.
Why Choose This Product?
This Dell adapter card is a solid fit for buyers seeking a branded storage expansion part with clearly identified Dell part numbers and support for dual M.2 NVMe SSDs. It is especially relevant for server and workstation users who need a PCIe-based solution for boot or storage expansion without unnecessary complexity. The card’s compatibility focus and dual-drive support make it a practical addition to many business hardware setups. For resellers, IT departments, and system builders, it offers a dependable way to extend storage capability using a compact expansion card format that aligns with Dell hardware environments.
About this adapter card
Dell M.2 PCIe dual SSD adapter card, part numbers 0NTRCY and 023PX6, carrying two NVMe SSDs on one bootable PCIe card. Tested and stocked in Doha, delivered across Qatar within a day.
Dell's M.2 PCIe dual SSD adapter, sold under part numbers 0NTRCY and 023PX6, is a PCIe expansion card with two M.2 slots for NVMe SSDs, allowing a server or workstation without M.2 sockets on its board to run NVMe storage and boot from it. It is the card ServerDove fits to one of its own Precision workstations to carry a 512GB NVMe drive, and it is offered here refurbished as a bare card.
Buyers in Qatar use it to add fast NVMe storage to Precision workstations and PowerEdge servers of the PCIe 3.0 generation, either as a boot pair or as a scratch and cache tier, without occupying drive bays. ServerDove keeps it in Doha stock.
- Slots
- 2 x M.2 NVMe
- Interface
- PCIe
- Part numbers
- 0NTRCY, 023PX6
- Boot support
- Yes
- Use
- Server or desktop
Part numbers and identification
Dell issued the card under two part numbers, which identify the same adapter. Buyers search for "0NTRCY", "023PX6", "Dell M.2 dual SSD adapter" and "Dell NVMe PCIe adapter card".
| SKU | ADP-DELL-M2-PCIe-2X |
| Dell part numbers | 0NTRCY, 023PX6 |
Specification
| Card type | PCIe expansion card |
| Drive support | 2 x M.2 NVMe SSD |
| Feature | NVMe boot and storage |
| Use case | Server and workstation |
Two NVMe drives on one card need eight PCIe lanes to run at full speed, and the host system must support PCIe bifurcation, splitting one x16 or x8 slot into two x4 links, for both drives to appear; Dell's Precision workstations and PowerEdge servers offer this in their BIOS on specific slots. In a slot without bifurcation only one drive is visible. Booting from the card depends on the system's UEFI firmware, which Dell's supports.
Two NVMe drives on this card give a workstation a fast boot drive and a scratch drive without using a single drive bay, and in a server they provide a mirrored boot pair that stays independent of the RAID controller and its drives, which simplifies rebuilding the storage later. M.2 drives of the 2280 length are the standard fit; the card carries the screws.
Installation
Fit the M.2 drives to the card with their retaining screws before installing it. Power the system down, seat the card in a PCIe x8 or x16 slot that the manual lists as supporting bifurcation, and enable that setting in the BIOS for the slot. Boot and confirm both drives appear in the BIOS storage list, then install the operating system in UEFI mode to boot from one, or mirror the pair in software.
In the box
- The system as described in the specification
- All installed components listed in the specification
- Power cable or power adapter
Images are for illustration. The unit supplied is the one described in the specification and may differ cosmetically.
Not included
- Monitor, keyboard and mouse
- Operating system or software licences
- Drives, memory or cards not listed in the specification
If you need rails, a bezel or additional drives, ask on WhatsApp before ordering and we will quote them with the unit.
Frequently Asked Questions
What does this Dell adapter card support?
It supports 2x M.2 NVMe SSDs through a PCIe expansion slot.
Can this card be used for boot drives?
Yes, it supports NVMe boot and storage applications.
Is this adapter intended for servers or workstations?
Yes, it is designed for server and workstation use.
What Dell part numbers are associated with this card?
The listed Dell part numbers are 0NTRCY and 023PX6.
What type of storage drives does it use?
It is designed for M.2 NVMe SSDs.
